Power Connection : L,N AC mains
Operating Voltage : 100~240V AC
Power Consumption : 2.3W max
DALI Connection : DA+/DA-, max. 300m cable length,
DALI power supply output current max 100mA.
Perm. Cable cross-section : 0.5~1.5㎟
Ambient Temperature : 0~+50 °C
Type of Protection : IP20
Protection Class : II
※ Each control circuit can supply DALI power for as many as 50 DALI devices.
※ The lighting system responds immediately and harmoniously
when the brightness level is changed at either of the control devices.
※ All that while allowing for the required comfortable,
easy and complete control over the lighting levels at any time.
※ Innovative Function to Power DALI Bus While Connected to AC Mains.
※ Powered by DALI Bus while not Connected to AC Mains.
